LORCH HandyTig 180 AC/DC ControlPro + KIT
search
  • LORCH HandyTig 180 AC/DC ControlPro + KIT

LORCH HandyTig 180 AC/DC ControlPro + KIT

HandyTIG 180 AC / DC ControlPro + KIT Optimal TIG welding for transfers
- Pulse function;
- Long duty cycle;
- Resistant to falls;
- ITC-Inside;
- Job memory. ControlPro
- User-oriented guidance;
- Infinitely adjustable welding current setting;
- Remote control connection;
- Exact-ampere digital display;
- Simple setting of the base parameters;
- Job memory;
- Powermaster torch remote control (in AC / DC);
- UpDown torch remote control (in AC / DC);
- Pulse function. KIT Electrode and solder return cables of 25 mm², 3 m; manual welding mask with soldering lens; brush steel; chipping hammer; TIG UP-Down torch, 4 m, with tungsten electrode, pressure reducer with quantity and content manometer, instruction manual.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

Intuitive operation Offering exceptional ease of use and intuitive operation, the Lorch HandyTIG series allows you to produce welding results of the highest order thanks to its automatic setting control. Non-contacting HF ignition The TIG arc is ignited without direct contact by high-voltage pulses. Ignition is triggered with the press of a button to ensure that the tungsten electrode does not come into contact with the workpiece. Putting an end to welds with tungsten inclusions, this technology reduces the strain on the electrode. When working in HF-sensitive environments or on tools, the operator has the additional option of switching to ContacTIG (contact ignition). Automatic gas management Automatic gas management is applied to automatically regulate the gas pre-flow and post-flow, thereby protecting electrode and weld pool against oxidation. Connection for hand or foot remote control. ControlPro
- User-oriented guidance;
- Infinitely adjustable welding current setting;
- Remote control connection;
- Exact-ampere digital display;
- Simple setting of the base parameters;
- Job memory;
- Powermaster torch remote control (in AC / DC);
- UpDown torch remote control (in AC / DC);
- Pulse function. KIT Electrode and solder return cables of 25 mm², 3 m; manual welding mask with soldering lens; brush steel; chipping hammer; TIG UP-Down torch, 4 m, with tungsten electrode, pressure reducer with quantity and content manometer, instruction manual
LR10801860

Data sheet

Ref
LR10801860
EAN
4032083116763
Brand
LORCH
ASIN code
B003P51LKK
Voltage setting
INFINITAMENTE VARIÁVEL
Duty cycle for Wigg 100% 40ºC
130 A
Duty cycle for Wigg 60% 40ºC
150 A
Duty cycle max.40ºC (%)
30 %
Protection Class
IP23S
Dimensions
337 X 130 X 211 / 480 X 185 X
Welding Range Electrode
5 - 150 A
Welding range TIG
3 - 180 A
Phases (50/60 Hz)
1 ~
Mains plug
SCHUKO
Fuse
16
Designation
CE, S
Insulation class
F
Standards
EN 60974-01
Weight
6,5 KG / 13,3 KG
Welding electrode
1,5 - 4,0 MM
Mains voltage
230 V
Permitted mains tolerance
15 % - 40 %

Specific References

EAN13
4032083116763
