ANi FeMale/Female Threaded Line Tap For Large Flow Capacity 15/MD

- Cylindrical gas thread - ISO 228 (BSPP);
- Gas conical thread - ISO 7 (BSPT).
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- INSTRUCTIONS: Valve open position: the lever is parallel to the body; Valve close position: the lever is perpendicular to the body;
- FIELDS OF APPLICATION: Pneumatic, oleodynamic and hydraulic circuits;
- PRESSURE: Maximum pressure 20 bar;
- OPERATING TEMPERATURE: -10°C (263°K), +120°C (393°K);
- MATERIALS USED: Body/Sleeve: Nickel-plated brass (UNI EN 12164 CW 614N); Shaft: Brass (UNI EN 12164 CW 614N); Ball: Chrome-platedBrass (UNI-EN 12164 CW614N); O-Ring: NBR 70; Ball seat seal washers: PTFE; Lever: Aluminium EN-AB46100; Seeger snap ring: Bronze; Screw: Zinc-plated steel;
- SURFACE TREATMENT: Chrome plating;
- THREAD: Cylindrical gas thread - ISO 228 (BSPP)Gas conical thread - ISO 7 (BSPT) - DIN 2999 - BS 21;
- These valves comply with the PED Directive (97/23 EC).
AH041602

Data sheet

Ref
AH041602
EAN
8022219006569
Brand
ANI
Model
15/MD
Weight
206 G
Shackle
1/2F

Specific References

EAN13
8022219006569
