ANi Line Tap With Milled Nut 21/D 3/8M

- Tap with milled nut 13/A;
- Cylindrical gas thread - ISO 228 (BSPP).
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- FIELDS OF APPLICATION: Pneumatic, oleodynamic and hydraulic circuits;
- AIRFLOW DIRECTION: Reversible inlets;
- PROCEDURE: 90° lever rotation;
- OPERATING PRESSURE: 0÷10 bar a 90°C;
- OPERATING TEMPERATURE: Min; -10°C (263°K), Max; +90°C (363°K);
- MATERIALS USED: Valve body: Chrome-plated Brass (CW614N UNI-EN 12164); Rod: Brass (CW614N UNI-EN 12164); Ring: Brass (CW614N UNI-EN 12164); Ball: Nickel-plated Brass (CW614N UNI-EN 12164); Ball seal washer: PTFE G200; Rod sealing ring: OR NBR 70 Sh; Lever: Nylon 66 glass reinforced; Screw: Steel C4C UNI/EN 10263/03; Nut: Nickel-plated ZAMAK-15 (UNI EN 1774:99);
- SURFACE TREATMENT: Chrome plating;
- THREAD: Cylindrical gas thread - ISO 228 (BSPP).
AH042303

Data sheet

Ref
AH042303
EAN
8022219007719
Brand
ANI
Model
21/D
Weight
126 G
Shackle
3/8M
Hose fitting length
10,2 MM

Specific References

EAN13
8022219007719
