ANi Female Threaded Inlet And Outlet Line Tap 21/F 1/4 F
search
  • ANi Female Threaded Inlet And Outlet Line Tap 21/F 1/4 F

ANi Female Threaded Inlet And Outlet Line Tap 21/F 1/4 F

- Cylindrical gas thread - ISO 228 (BSPP).
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- FIELDS OF APPLICATION: Pneumatic, oleodynamic and hydraulic circuits;
- AIRFLOW DIRECTION: Reversible inlets;
- PROCEDURE: 90° lever rotation;
- OPERATING PRESSURE: 0÷10 bar a 90°C;
- OPERATING TEMPERATURE: Min; -10°C (263°K), Max; +90°C (363°K);
- MATERIALS USED: Valve body: Chrome-plated Brass (CW614N UNI-EN 12164); Rod: Brass (CW614N UNI-EN 12164); Ring: Brass (CW614N UNI-EN 12164); Ball: Nickel-plated Brass (CW614N UNI-EN 12164); Ball seal washer: PTFE G200; Rod sealing ring: OR NBR 70 Sh; Lever: Nylon 66 glass reinforced; Screw: Steel C4C UNI/EN 10263/03; Nut: Nickel-plated ZAMAK-15 (UNI EN 1774:99);
- SURFACE TREATMENT: Chrome plating;
- THREAD: Cylindrical gas thread - ISO 228 (BSPP).
AH042502

Data sheet

Ref
AH042502
EAN
8022219007788
Brand
ANI
Model
21/F
Weight
92 G
Shackle
1/4F
10 MM
Thread height 1
9 MM

Specific References

EAN13
8022219007788
