  • BELFLEX Industrial Machine for Metal BF 520C TME

BELFLEX Industrial Machine for Metal BF 520C TME

Included accessories:
- 3 jaws Chuck Ø125 mm;
- MT2 Centre;
- MT3 Centre;
- Kit of Tools;
- Stand.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Metalworking lathes for professional purpose, equipped with prismatic, rolled and rectified ways;
- Shaft of guide for automatic feeds;
- Longitudinal and cross rapid traverse;
- Stop emergency switch, tool rest and chuck guard;
- Limit microswitch in cover and chuck guard;
- Declaration of conformity and equipment CE.
AB441220000

Data sheet

Ref
AB441220000
EAN
8423640052000
Brand
BELFLEX
ASIN code
B00SP8YCDU
Weight
110 KG
Dimensions
1250 X 570 X 570 MM
Speed change
ENGRENAGEM
Taper of tailstock sleeve
MT2
Diameter tailstock sleev
30 MM
Max. swing over bed
200 MM
Max. swing over cross slide
125 MM
Distance between centres
520 MM
Long. feeds range
0,05-0,20 MM/REV.
Metric threads range
11 TIPOS / 0,4-3 MM
Inch threads range
11 TIPOS / 8-32 TPI
Spindle bore
20 MM
Travel tailstock sleeve
35 MM
Number of speeds
6
Taper spindle bore
MT3
Power input
0,55 KW - 0,75 HP
Spindle speed range
140-1710 RPM
DRO X-Y
NÃO
Voltage
230V-F1

Specific References

EAN13
8423640052000
