LORCH M-Pro 150 CuSi ControlPro
search
  • LORCH M-Pro 150 CuSi ControlPro

LORCH M-Pro 150 CuSi ControlPro

M-Pro 150 CuSi LORCH ControlPro
MIG-MAG at the highest level using mixed gas and CO₂.
- Soldering functionality;
- Automatic setting control;
- Precise wire feeding;
- Intuitive operation.
ControlPro
- With automatic setting control;
- 4-roll wire feeder;
- Volt and ampere display;
- User-oriented operator guidance using illuminated symbols.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

Automatic setting controlThe automatic setting control lets you find the welding parameter setting that works best for you. Start by selecting the desired material/wire/gas combination from the synergic line-program table. Next, set the number corresponding to the welding program using the selector switch in the wire feeder housing.

Intuitive operationThanks to the clearly structured user interface and the slanted operating panel, the device control remains well visible throughoutoperation and affords the user an ergonomic operating position.

Energy-efficientEnergy management is a standard feature built into every model of the Lorch M-Pro series. The energy saving features include a fan that only comes on only when necessary in order to cut down on unnecessary energy consumption during stand-by.

Industrial housingThe housing of Lorch's M-Pro series has been designed specifically to meet the requirements of industrial enterprises. This compactand rugged housing allows you to easily stow your power so
LR21801510

Data sheet

Ref
LR21801510
EAN
4032083117876
Brand
LORCH
Voltage setting
7 ESCALAS
Duty cycle for Wigg 100% 40ºC
100 A
Duty cycle for Wigg 60% 40ºC
120 A
Duty cycle max.40ºC (%)
40 %
Protection Class
IP23S
Dimensions
880 X 400 X 755
Phases (50/60 Hz)
3 ~
Mains plug
CEE 16
Fuse
16
Designation
CE, S
Insulation class
F
Standards
EN 60974 - 01
Weight
66 KG
Mains voltage
400 V
Permitted mains tolerance
15 % - 15 %
Wire feed unit
4 ROLOS 2 ACIONÁVEIS
Welding range
15 - 150 A
Weldable wires steel
0,6 - 1,0 MM
Wedable wires aluminium
0,8 - 1,0 MM
Phases 2 (50/60 Hz)
-'
Weldable wires cusi
0,8 - 1,0 MM
Mains voltage 2
-

Specific References

EAN13
4032083117876
