LORCH M-Pro 200 CuSi ControlPro
search
  • LORCH M-Pro 200 CuSi ControlPro

LORCH M-Pro 200 CuSi ControlPro

M-Pro 200 CuSiControlPro
MIG-MAG at the highest level using mixed gas and CO₂.
- Soldering functionality;
- TipTronic;
- Automatic setting control;
- Precise wire feeding;
- Intuitive operation.
ControlPro
- With automatic setting control;
- 4-roll wire feeder;
- Volt and ampere display;
- User-oriented operator guidance using illuminated symbol.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

TipTronicUsing the TipTronic facility, you save your ideal setting for each weld so that you can effortlessly retrieve the settings one at atime using the Up-Down torch when performing recurring welding tasks.

Automatic setting controlThe automatic setting control lets you find the welding parameter setting that works best for you. Start by selecting the desired material/wire/gas combination from the synergic line-program table. Next, set the number corresponding to the welding program using the selector switch in the wire feeder housing. When working with the Performance operating panel, you make your selection entirely on the OLED display.

Intuitive operationThanks to the clearly structured user interface and the slanted operating panel, the device control remains well visible throughoutoperation and affords the user an ergonomic operating position.

Energy-efficientEnergy management is a standard feature built into every model of the Lorch M-Pro series. The energy saving features include a fan tha
LR21802010

Data sheet

Ref
LR21802010
EAN
4032083117890
Brand
LORCH
Voltage setting
12/21 ESCALAS
Duty cycle for Wigg 100% 40ºC
100 A
Duty cycle for Wigg 60% 40ºC
130 A
Duty cycle max.40ºC (%)
20 %
Protection Class
IP23S
Dimensions
880 X 400 X 755
Phases (50/60 Hz)
3 ~
Mains plug
CEE 16
Fuse
16
Designation
CE, S
Insulation class
F
Standards
EN 60974 - 01
Weight
68 KG
Mains voltage
400 V
Permitted mains tolerance
15 % - 15 %
Wire feed unit
4 ROLOS
Welding range
15 - 200 A
Weldable wires steel
0,6 - 1,0 MM
Wedable wires aluminium
0,6 - 1,2 MM
Phases 2 (50/60 Hz)
-
Weldable wires cusi
0,6 - 1,2 MM
Mains voltage 2
-

Specific References

EAN13
4032083117890
