LORCH S3 SpeedPulse Mobil gas-cooled
search
  • LORCH S3 SpeedPulse Mobil gas-cooled

LORCH S3 SpeedPulse Mobil gas-cooled

With SpeedPulse XT: extra robust, extra variable, extra low-spatter.
- Variable arc length control;
- Dynamic control;
- Ready for Speed XT;
- EN 1090-certified;
- Mobile pulse welding machine.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

Ready for Speed XTYou can now finish your welding jobs even faster by taking advantage of Lorch's optional speed upgrades SpeedRoot, SpeedUp and SpeedCold as well as of the standard options SpeedPulse, SpeedPulse XT, SpeedTwinPuls, TwinPuls XT, SpeedArc and SpeedArc XT.

MobilityOur Lorch S3 mobile SpeedPulse XT with trolley wheelset will meet all your mobility needs as it allows you to both carry the unit and move it on its wheels.

Dynamic controlDynamic control allows the welder, for the first time, to variably adjust a pulse welding machine to a wide range of jobs and welding positions as well as to his personal preferences. The welder can use a controller to directly access the arc characteristic and change it from soft to hard.

Ready for PulseHighly developed processor technology provides for the seamless interaction of all parameters and components involved in the welding process. The results of this smooth interaction are superior duty cycle levels and maximum productivity.

Powerful
The 300 to
LR22032001

Data sheet

Ref
LR22032001
EAN
4032083121149
Brand
LORCH
ASIN code
B01KOLTJWY
Voltage setting
CONTÍNUO
Duty cycle for Wigg 100% 40ºC
250 A
Duty cycle for Wigg 60% 40ºC
280 A
Duty cycle max.40ºC (%)
40 %
Protection Class
IP23S
Dimensions
-
Phases (50/60 Hz)
3 ~
Mains plug
CEE 16
Fuse
16 A
Designation
CE, S
Insulation class
F
Standards
EN 60974 - 01
Weight
34 KG
Mains voltage
400 V
Permitted mains tolerance
15% - 15%
Wire feed unit
4 ROLOS 2 ACIONÁVEIS
Welding range
25 - 320 A
Weldable wires steel
0,6 - 1,6 MM
Wedable wires aluminium
1,0 - 1,2 MM
Dimensions A version
812X340X518
Dimensions B version
-
Weight wire feed case
-
Weight, water cooling
-
Weight power source A version
-

Specific References

EAN13
4032083121149
