MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-93D 93t
search
  • MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-93D 93t

MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-93D 93t

- Working pressure: 700 kg/cm2/10.000 psi;
- Hydraulic return;
- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;
- Bronze guide and scraper seal that prevents the entry of dirt;
- With carrying handle;
- With pins.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Working pressure: 700 kg/cm2/10.000 psi;
- Hydraulic return;
- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;
- Bronze guide and scraper seal that prevents the entry of dirt;
- The hydraulic force being applied in both directions, these cylinders are very solid and used where a precision operation is required to move or position loads accurately on the assembly place;
- Widely demanded in public works and big structure manufacture;
- Fitted with a relief safety valve, ref. A-5538 on the piston retract side, to prevent accidental overpressure;
- With carrying handle;
- With pins.
CDRA-93D

Data sheet

Ref
CDRA-93D
EAN
5608907563045
Brand
MEGA
Color
GREY
Minimum height
421 MM
Oil capacity
E 1992 CM³/T 692 CM³
Rated Capacity
93 T
Stroke
150 MM
Weight
60,3 KG
Effective Area
E 132,73 CM²/T 46,14 CM²

Specific References

EAN13
5608907563045
