STAHLWILLE Electronic SENSOTORK® 713R Tightening Angle Torque Wrenche with Reversible Ratchet Insert Tool
search
  • STAHLWILLE Electronic SENSOTORK® 713R Tightening Angle Torque Wrenche with Reversible Ratchet Insert Tool

STAHLWILLE Electronic SENSOTORK® 713R Tightening Angle Torque Wrenche with Reversible Ratchet Insert Tool

‘- Backlit display improves legibility and evaluation of the tightening operation (traf« c-light colours);
- All functions are selected using the arrow keys. The visual guidance system makes operation a simple matter;
- Improved ergonomics for strain-free working;
- Measurements independent of the point of application of force;
- Convenient angle measurement across a very wide angle range;
- Warning signals: acoustic (buzzer), tactile (vibration in the handle), visual (LEDs and display). The point at which the warning signal is triggered can be freely set;
- Data output USB interface;
- Easy extension setting. Where the insert tool requires an extension adjustment, simply enter the new value. Recalculation using complicated formulae is no longer necessary;
- QuickRelease;
- Firm locking and rapid change of any insert tools.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

‘- Simple, flexible operation thanks to operator guidance on large-format display;
- Very broad measuring range (5% to 100% of rated value);
- Supplied with insert tool reversible ratchet;
- More insert tools;
- QuickRelease safety lock;
- For clockwise and anticlockwise torqueing;
- Measurements independent of the point of application of force;
- Units of measurement: N·m, ft·lb, in·lb;
- Advance warning points programmable for visual, tactile and acoustic signals;
- Torque and angle are simultaneously visible;
- New: backlit display aids evaluation of the tightening operation (traffic-light colours);
- Insert tool lengths can be individually set;
- Maintenance friendly due to easy adjustment and automatic reminder of next calibration date;
- Repeated joints can be collated to form a single menu-guided sequence;
- New: tightening jobs are stored with a timestamp;
- Individual identification markings possible;
- Password protection to prevent inadvertent changes and make the tool tamper-proof;
- Meets requir
S96501606

Data sheet

Ref
S96501606
EAN
4018754156504
Brand
STAHLWILLE
ASIN code
B00R3AY2VI
Total length
378 MM
Weight
856 G
Type
SENSOTORK® 713R
Height
24 MM
Diameter
33 MM
Size
6
Torque range
3 - 60 N·M
