STAHLWILLE Service MANOSKOP® Torque Wrench with Permanently Installed QuickRelease Ratchet Tamanho 20QR FK

In sturdy plastic case (size 65 in steel case). Ratchet has QuickRelease safety lock. Deviation of indication ± 4%.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Click-type;
- Mount for interchangeable insert tools;
- QuickRelease safety lock;
- Fast, accurate setting thanks to QuickSelect quick-action adjuster;
- Dual stop signal;
- Easy-to-read double scale with colour coding to differentiate between N·m/ft·lb and ft·lb/in·lb scales;
- The measuring element is only under load while force is being applied, no need for manual reset to zero;
- Can be applied for either clockwise or anticlockwise tightening by turning the inserts over;
- Any force applied to the tool after the 'click' or applied in the opposite direction to the current function – e.g. forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it;
- Two-component handle with ergonomically designed green softer layers (resistant to oils, grease, fuels, brake fluids and Skydrol);
- Calibration using perfectControl calibrating unit nº 7794 or calibration system No 7706. Adjustment without disassembly;
- With certificate;
- Registered design;
- Display deviatio
S96502120

Data sheet

Ref
S96502120
EAN
4018754180516
Brand
STAHLWILLE
ASIN code
B00OHQ09U4
Total length
526 MM
Weight
1589 G
Type
MANOSKOP® 730N
Diameter
28 MM
Size
20QR FK
Torque range
40 - 200 N·M
Scale division
10 N·M
Diameter 2
41 MM
Height 2
18 MM
Height 1
23 MM

Specific References

EAN13
4018754180516
