STAHLWILLE Service MANOSKOP® 730N Torque Wrenches with Permanently Installed Fine-Tooth Ratchet Size 65 FK-HD
search
  • STAHLWILLE Service MANOSKOP® 730N Torque Wrenches with Permanently Installed Fine-Tooth Ratchet Size 65 FK-HD

STAHLWILLE Service MANOSKOP® 730N Torque Wrenches with Permanently Installed Fine-Tooth Ratchet Size 65 FK-HD

In sturdy plastic case (size 65 in steel case). Deviation of indication ± 4%.
  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Click-type;
- Mount for interchangeable insert tools;
- QuickRelease safety lock;
- Fast, accurate setting thanks to QuickSelect quick-action adjuster;
- Dual stop signal;
- Easy-to-read double scale with colour coding to differentiate between N·m/ft·lb and ft·lb/in·lb scales;
- The measuring element is only under load while force is being applied, no need for manual reset to zero;
- Can be applied for either clockwise or anticlockwise tightening by turning the inserts over;
- Any force applied to the tool after the 'click' or applied in the opposite direction to the current function – e.g. forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it;
- Two-component handle with ergonomically designed green softer layers (resistant to oils, grease, fuels, brake fluids and Skydrol);
- Calibration using perfectControl calibrating unit nº 7794 or calibration system No 7706. Adjustment without disassembly;
- With certificate;
- Registered design;
- Display deviatio
S96502265

Data sheet

Ref
S96502265
EAN
4018754221554
Brand
STAHLWILLE
ASIN code
B00OHQH7XG
Total length
944 MM
Weight
3698 G
Type
MANOSKOP® 730N
Diameter
30,6 MM
Size
65 FK-HD
Torque range
130 - 650 N·M
Scale division
50 N·M
Diameter 2
58 MM
Height 2
36 MM
Height 1
25,6 MM

Specific References

EAN13
4018754221554
