STAHLWILLE Standard MANOSKOP® 721 Quick Torque Wrenches Permanently Installed Ratchet
search
  • STAHLWILLE Standard MANOSKOP® 721 Quick Torque Wrenches Permanently Installed Ratchet

STAHLWILLE Standard MANOSKOP® 721 Quick Torque Wrenches Permanently Installed Ratchet

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Click-type;
- Rapid setting thanks to easy-action locking lever in the handle;
- Ergonomically designed, non-slip adjuster with a thumb recess;
- Magnifying glass integrated in the display window;
- Dual stop signal;
- Twin scales N·m/ft·lb;
- The measuring element is only under load while force is being applied, no need for manual reset to zero;
- Optimised convex handle for strain-free working;
- Any force applied to the tool after the 'click' or applied in the opposite direction to the current function – e.g. forcible loosening of a jammed screw - does not act on the trigger mechanism and cannot cause damage to it;
- All the sensitive components are protected by the sturdy tubular steel housing;
- Calibration using perfectControl calibrating unit No 7794 or calibration system No 7706. Adjustment without disassembly;
- With certificate;
- Display deviation value ± 4%.
S50204015

Data sheet

Ref
S50204015
EAN
5608907545744
Brand
STAHLWILLE
Total length
452,5 MM
Weight
1280 G
Type
MANOSKOP® 721
Diameter
28 MM
Size
15
Torque range
30 - 150 N·M
Scale division
5 N·M
Diameter 2
41 MM
Height 2
18 MM
Height 1
23 MM

Specific References

EAN13
5608907545744
