  • MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-23D 23t

MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-23D 23t

- Working pressure: 700 kg/cm2/10.000 psi;

- Hydraulic return;

- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;

- Bronze guide and scraper seal that prevents the entry of dirt.

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Working pressure: 700 kg/cm2/10.000 psi;

- Hydraulic return;

- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;

- Bronze guide and scraper seal that prevents the entry of dirt;

- The hydraulic force being applied in both directions, these cylinders are very solid and used where a precision operation is required to move or position loads accurately on the assembly place;

- Widely demanded in public works and big structure manufacture;

- Fitted with a relief safety valve, ref. A-5538 on the piston retract side, to prevent accidental overpressure.

CDRA-23D

Fiche technique

Ref
CDRA-23D
EAN
5608907520758
Marca
MEGA
Cor
CINZENTO
Altura mínima
310 MM
Capacidade de óleo
E 500 CM³/T 155 CM³
Força nominal
23 T
Percurso
150 MM
Peso
10,4 KG
Seção útil
E 33,18 CM²/T 10,28 CM²

Références spécifiques

EAN-13
5608907520758
