7380N CONTROLADOR DE ANGULOS
search
  • 7380N CONTROLADOR DE ANGULOS

7380N CONTROLADOR DE ANGULOS

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- For angle controlled bolt/screw tightening, with static read-off point;

- Read-off possible from any angle thanks to a pair of angled scales;

- Removable magnet for attaching sockets with 1/2 internal square drive;

- For use in conjunction with tightening tools such as Service MANOSKOP® No 730N;

- Since this tightening method requires a pre-determined snug torque to be applied, it is essential to choose a torque wrench covering both snug torque as well as maximum torque required to reach the recommended tightening angle. Whether 1/2 or 3/4 sq.dr;

- Torque Angle Gauge is used depends upon the square drive of the appropriate torque wrench employed.

S54010001

Fiche technique

Ref
S54010001
EAN
4018754136124
Marca
STAHLWILLE
Código ASIN
B003QHFTIM
Comprimento total
416 MM
Peso
494 G
Altura
43 MM
Diâmetro
78 MM
Tamanho
"1/2"""
Alcance do torque
± 360°
Divisão da escala
2°
Número
7380N

Références spécifiques

EAN-13
4018754136124
