ANi Blow Gun With Rubber Protection 25/B2 ALFA 11/A
search
  • ANi Blow Gun With Rubber Protection 25/B2 ALFA 11/A

ANi Blow Gun With Rubber Protection 25/B2 ALFA 11/A

Nickel-plated ZAMAK nozzle.

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Professional blow gun of the 25/B series with progressive opening valve. 1/4F BSP threaded nickel-plated aluminium body. Available with different kinds of nozzle. FIELDS OF APPLICATION: Compressed air;

- WEIGTH: 25/B1 198 g; MATERIALS USED:

- Body: Aluminium (Al Si 11 Cu 2 (Fe) UNI EN 1706);

- Lever: Nickel-plated steel (Fe P01-P02-P04 UNI EN 10025);

- Rivet: Zinc-plated steel (CB4FF EN 10263/2);

- Valve: Acetal resin Ultraform® N2320/Brass (CW614N UNI-EN 12164)/NBR 70;

- Spring: Stainless steel (AISI 302 UNI EN 10088-3);

- Seal washers: NBR 70;

- Nozzle/Tubes: Nickel-plated brass (CW614N UNI-EN 12164), Aluminium (Al- Mg S UNI EN 573/3), zinc-plated steel (11SMn Pb37 UNI 10277-3); OPERATING TEMPERATURE: -10°C (253°K), +90°C (343°K); THREAD: Cylindrical gas thread- ISO 228 (BSPP); OPERATING PRESSURE: Maximum recommended pressure 10 bar; CRUSH RESISTANCE: 350 kg. Max.

AH050311

Scheda tecnica

Ref
AH050311
EAN
8022219009362
Marca
ANI
Código ASIN
B01ENKFX1S

Riferimenti Specifici

ean13
8022219009362
