MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-55F 55t

- Working pressure: 700 kg/cm2/10.000 psi;

- Hydraulic return;

- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;

- Bronze guide and scraper seal that prevents the entry of dirt;

- With carrying handle.

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

- Working pressure: 700 kg/cm2/10.000 psi;

- Hydraulic return;

- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;

- Bronze guide and scraper seal that prevents the entry of dirt;

- The hydraulic force being applied in both directions, these cylinders are very solid and used where a precision operation is required to move or position loads accurately on the assembly place;

- Widely demanded in public works and big structure manufacture;

- Fitted with a relief safety valve, ref. A-5538 on the piston retract side, to prevent accidental overpressure;

- With carrying handle.

CDRA-55F

Opis

Ref
CDRA-55F
EAN
5608907326084
Marca
MEGA
Cor
CINZENTO
Altura mínima
321 MM
Capacidade de óleo
E 1965 CM³/T 707 CM³
Força nominal
55 T
Percurso
250 MM
Peso
37 KG
Seção útil
E 78,54 CM²/T 28,28 CM²
