LORCH HandyTig Basic 180 DC + KIT

HandyTig Basic 180 DC + KIT Optimal TIG welding for transfers

- Pulse function;

- Long duty cycle;

- Resistant to falls;

- ITC-Inside;

- Job memory. Basic

- User-oriented operator guidance using illuminated symbols;

- Infinitely adjustable welding current setting;

- Remote control connection. KITElectrode and solder return cables of 25 mm², 3 m; manual welding mask with soldering lens; brush steel; chipping hammer; TIG torchwith tungsten electrode, pressure reducer with quantity and content manometer, instruction manual

  Security policy

Security policy (edit with the Customer Reassurance module)

  Delivery policy

Delivery policy (edit with the Customer Reassurance module)

  Return policy

Return policy (edit with the Customer Reassurance module)

Intuitive operationOffering exceptional ease of use and intuitive operation, the Lorch HandyTIG series allows you to produce welding results of the highest order thanks to its automatic setting control. Non-contacting HF ignitionThe TIG arc is ignited without direct contact by high-voltage pulses. Ignition is triggered with the press of a button to ensure that the tungsten electrode does not come into contact with the workpiece. Putting an end to welds with tungsten inclusions, this technology reduces the strain on the electrode. When working in HF-sensitive environments or on tools, the operator has the additional option of switching to ContacTIG (contact ignition). Automatic gas managementAutomatic gas management is applied to automatically regulate the gas pre-flow and post-flow, thereby protecting electrode and weldpool against oxidation. Connection for hand or foot remote control We offer a variety of hand or foot remote controls for the Lorch HandyTIG 180 that allow you to step into the welding p

LR10801802

Datablad

Ref
LR10801802
EAN
4032083116626
Marca
LORCH
Ajuste de tensão
INFINITAMENTE VARIÁVEL
CC em modo Wigg 100% 40ºC
130 A
CC em modo Wigg 60% 40ºC
150 A
CC à corrente máxima 40ºC (%)
30 %
Classe de proteção
IP23S
Dimensões
337 X 130 X 211 / 480 X 185 X
Faixa Soldagem Eletrodo
5 - 150 A
Faixa Soldagem TIG
3 - 180 A
Fases (50/60 HZ)
1 ~
Ficha de alimentação
SCHUKO
Fusivel
16
Indicação
CE, S
Classe isolamento
F
Normas
EN 60974-01
Peso
6,5 KG / 13,3 KG
Soldadura Electrodo
1,5 - 4,0 MM
Tensão de rede
230 V
Tolerância de alimentação
15 % - 40 %
